Description
Magnetic driven pump is a new type of non-sealed pump which adopts the principle of permanent magnet transmission technology to realize the contactless transfer of torque. 0.5 hp (0.75 kW) magnetic drive centrifugal pump adopts ETFE material of casing.
Features:
- ETFE (carbon-fiber reinforced) wetted-end material.
- Able to handle many types of chemical and temperature up to 90 ℃.
- Available in flange connections.
Specification:
| Model | ATO-350PW-F | |
| Specific Gravity | 1.2 | |
| Frequency | 50Hz, 60Hz | |
| Rated Voltage | 3-phase 380V (contact us for other voltages) | |
| Pump performance at specific point (M-L/min) | 50Hz | 10-80 |
| 60Hz | 11-80 | |
| Motor Output | 0.5 HP (0.37 kW) | |
| Flange Size | 25 mm (outlet); 25 mm (inlet) | |
| Casing Material | ETFE | |
| Shaft Material | ceramic | |
| Bearing Material | carbon | |
| O-ring Material | FKM | |
| Interface Mode | thread, flange | |
| Net Weight | 16kg |
Structure:
Dimension (Unit: mm)
| Model | W | H | L | a | b | c | d | e | f |
| 350PW-F | 157 | 257 | 472 | 232.5 | 130 | 161 | 130 | 115 | 88 |
Tips: What is Specific Gravity?
Specific gravity is also called relative density. The specific gravity of a solid or liquid is the ratio of the density of the substance (in a fully dense state) to the density of pure H2O at 3.98 ℃ at standard atmospheric pressure. The specific gravity of a gas is the ratio of the density of the gas to the density of air under standard conditions. The specific gravity of a liquid or solid tells whether it sinks or floats in another fluid. It is commonly used in industries such as metallurgy, geology, and chemistry to determine the purity and quality of materials.
