Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 117 Cv
- Pipe/Port Type and Size: NPT 2-1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 77°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 104°
- Product Weight: 0 lbs
- Voltage and Frequency: 480 AC with 60 Hz
- Watt Rating: 28.2 W
- Holding Current (VA): 51
- Orifice Size: 3 in
- Coil Class: FT
- Coil Number: 206409-013-D
- Lead Length: Vertical and Upright, 18 inch
- Carton Note: 2-1/2 X 3 2NC AL 28.2/F AC
- Kit Number: 302354-VM
