Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 5.1 Cv
- Pipe/Port Type and Size: NPT 3/4
- Media: Air, Inert Gas, Fuel Gas
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 104°
- Product Weight: 1.39 lbs
- Voltage and Frequency: 120 AC with 60 Hz
- Watt Rating: 11.8 W
- Holding Current (VA): 23
- Orifice Size: 3/4 in
- Coil Class: FT
- Coil Number: 064982-004-D
- Lead Length: 18 inch
- Mounting Brackets: Optional
- Carton Note: 3/4 X 3/4 2NC ALUM 11.8/F AC
- Kit Number: 302350
