ASCO 8215G030DC12/DCD – Fuel, Gas, and Oil Valve

Description

Specifications

• Valve Actuation: Solenoid – Direct Acting
• Function: 2 way – 2/2 Normally Closed
• Body Material: Aluminum
• Flow (Cv): 5.1 Cv
• Pipe/Port Type and Size: NPT 3/4
• Min Ambient Temperature: 32°
• Max Ambient Temperature: 104°
• Min Fluid Temperature: 32°
• Max Fluid Temperature: 104°
• Product Weight: 1.81 lbs
• Voltage and Frequency: 12 Volts DC
• Watt Rating: 11.6 W
• Orifice Size: 3/4 in
• Coil Class: FT
• Coil Number: 238710-004-D
• Lead Length: Any, 18 inch
• Carton Note: 3/4 X 3/4 2NC AL 11.6/F DC
• Kit Number: 302430
• Order Code: 20301
