Description
Specifications
- Function: 2 way – 2/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 8.8 Cv
- Pipe/Port Type and Size: NPT 3/4
- Media: Steam
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 210°
- Product Weight: 1.19 lbs
- Voltage and Frequency: 220 Volts AC with 50 Hz
- Watt Rating: 10.1 W
- Orifice Size: 3/4 in
- Coil Class: FT
- Coil Number: 238610-058-D
- Lead Length: 18 inch, Any
- Carton Note: 3/4 X 3/4 2NC BRASS 10.1/F AC
- Kit Number: 323469
