Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Open
- Body Material: Brass
- Flow (Cv): 12.5 Cv
- Pipe/Port Type and Size: NPT 1
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Max Fluid Temperature: 180°
- Product Weight: 7.81 lbs
- Voltage and Frequency: 220 AC with 60 Hz
- Watt Rating: 6.1 W
- Holding Current (VA): 16
- Orifice Size: 1 in
- Coil Class: FT
- Coil Number: 238210-054-D
- Mounting Direction: 18 inch, ANY
- Carton Note: 1 X 1 3NO BRASS 6.1/F AC
- Kit Number: 302671-MO
