Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Open
- Body Material: Brass
- Flow (Cv): 4.8 Cv
- Pipe/Port Type and Size: NPT 3/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 4.1 lbs
- Voltage and Frequency: 115 AC with 50 Hz
- Watt Rating: 8.1 W
- Holding Current (VA): 16
- Orifice Size: 11/16 in
- Coil Class: FT
- Coil Number: 238210-033-D
- Lead Length: ANY, 18 inch
- Mounting Brackets: OPTIONAL
- Carton Note: 3/4 X 11/16 3NO BRASS 8.1/F AC
- Kit Number: 314492
Reviews
There are no reviews yet.
