Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 4 way
- Body Material: Brass
- Flow (Cv): 1.4 Cv
- Pipe/Port Type and Size: NPT 1/2
- Media: Air, Inert Gas, Light Oil, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 150 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 125 psi
- Min Operating Pressure (Light Oil): 25 psi
- Max Operating Pressure (Light Oil): 125 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 9.59 lbs
- Voltage and Frequency: 440, 480 Volts AC with 50/60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 3/8 in
- Coil Class: FT
- Coil Number: 238610-088-D
- Lead Length: 18 inch, Any
- Carton Note: 1/2 X 3/8 4W BRASS 10.1/F AC
