Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 3.2 Cv
- Pipe/Port Type and Size: NPT 1/2
- Media: Air, Inert Gas, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 250 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 250 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Max Fluid Temperature: 180°
- Product Weight: 4.1 lbs
- Voltage and Frequency: 110 AC with 50 Hz
- Watt Rating: 17.1 W
- Holding Current (VA): 40
- Orifice Size: 5/8 in
- Coil Class: HB
- Coil Number: 238814-132-D
- Lead Length: ANY, 18 inch
- Mounting Brackets: OPTIONAL
- Carton Note: 1/2 X 5/8 3NC BRASS 17.1/H AC
- Kit Number: 314495-V
