Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Stainless Steel
- Flow (Cv): 4 Cv
- Pipe/Port Type and Size: NPT 1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 140°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 125°
- Product Weight: 0 lbs
- Voltage and Frequency: 208 AC with 60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 5/8 in
- Coil Class: HT
- Coil Number: 238810-052-D
- Mounting Direction: 18 inch, ANY
- Carton Note: 1/2 X 5/8 3NC S.S. 10.1/H AC
- Kit Number: 318400-V
