Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Stainless Steel
- Flow (Cv): 1.8 Cv
- Pipe/Port Type and Size: NPT 3/8
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 149°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 149°
- Voltage and Frequency: 24 Volts DC
- Watt Rating: 0.48 W
- Orifice Size: 5/16 in
- Coil Class: H
- Coil Number: 298008-002
- Carton Note: 3/8 X 5/16 3NC S.S. 0.48/H DC
- Kit Number: 325074-V
