ASCO SC8353G052AC220/50 – Solenoid Valve

Description

Specifications

• Valve Actuation: Solenoid
• Function: 2 way – 2/2 Normally Closed
• Body Material: Aluminum
• Flow (Cv): 20 Cv
• Pipe/Port Type and Size: NPT 3/4
• Min Ambient Temperature: 0°
• Max Ambient Temperature: 150°
• Min Fluid Temperature: 0°
• Max Fluid Temperature: 150°
• Voltage and Frequency: 220 Volts AC with 50 Hz
• Watt Rating: 6.1 W
• Holding Current (VA): 16
• Orifice Size: 1-1/8 in
• Coil Class: FT
• Coil Number: 238212-058
• Mounting Direction: Any
• Carton Note: 3/4 X 1-1/8 2NC 8.1/F AC
• Kit Number: 316563
