Belimo F6250-300SHP+SY4-110 2-Way 10″ Inch Butterfly Valve, ANSI Class 300, Cv 3517 + Non Fail-Safe Industrial Valve Actuator, 120VAC, On/Off, Floating Point Control Signal, 2x SPDT, NEMA 4X, 2-Year Warranty

Description

Belimo F6250-300SHP+SY4-110 : 2-Way 10″ Inch Butterfly Valve, ANSI Class 300, Cv 3517 + Non Fail-Safe Industrial Valve Actuator, 120VAC, On/Off, Floating Point Control Signal, 2x SPDT, NEMA 4X, 2-Year Warranty

Belimo F6250-300SHP high performance butterfly valve assembly with SY4-110 actuator provides dependable flow control for chilled water and hot water HVAC hydronic systems. The actuator supports floating or 3-point control and common building automation sequences. Use the specifications below to confirm pressure class, Cv, voltage, control signal, and enclosure rating before ordering.

Belimo F6250-300SHP Valve Specifications

ANSI Class	300
Pattern	2-way
Cv	3517
Fluid	Chilled or hot water, up to 60% glycol, steam
Body Pressure Rating	ANSI Class 300
End Fitting	Flange
Valve Size	10″ [250]



Belimo SY4-110 Valve Actuator Specifications
